Transactive Energy for Microgrids

Tags :

Our CEO Kay Aikin wrote a guest blog for Microgrid Knowledge the premier industry newsletter focused on Microgrid technologies and policy.

MRRA Microgrid

MRRA Microgrid

Toward Market-based Microgrid Control Systems

The largest machine on earth is often said to be our electrical grid. By the end of 2016 there were some 7600 power plants greater than 1 MW with many times more, smaller resources and an even larger number of control systems. The grid is truly a complex machine that is made up of systems collected into ever larger systems.  In the controls world this is called a systems of systems. This is the ultimate in complexity and is true on all large systems like the electric grid and ecological systems.

The advantage of microgrids is they help us tame the complexity the grid by limiting the number of possible interactions within the grid. Smaller more predictable systems are less prone to unintended consequences as can happen in the electrical grid like the Northeast blackout of 2003. However, even with microgrids and the emergence of energy management systems and smart devices the control networks of a microgrid will become even more complex. But this complexity can be used to build better systems as Ecologist Eric Berlow says the more you “embrace complexity the better chance you have finding simple answers”. A great Ted talk illustrating this concept can be seen at: https://www.ted.com/talks/eric_berlow_how_complexity_leads_to_simplicity

It has been shown that market-based systems can be amazingly stable in complex environments because of the many naturally balancing feedback loops within the system. Using this complexity, to lead to simplicity. In the electrical engineering field, the GridWise Alliance has called this idea of market-based system “Transactive Energy”. Much of the research in this area has been done by the Pacific Northwest National Laboratory and one of the successful trials was the Olympia Peninsula Project (OPP) consisting of a field demonstration of price signal-based control of distributed energy resources. The demonstration showed that market-based control was able to manage distribution constraints and reduce peak loads. This was followed with the Pacific Northwest Demonstration Project (PNDP) ending in 2015.

You can consider there to be three main methods for implementing Transactive Energy control systems applicable to microgrids including:

  • Centralized (top down)
  • Centralized (auction-based)
  • Distributed (edge-based)

The difference between the Olympia Peninsula and Pacific Northwest Project was that OPP was a double auction very similar to the current ISO systems and PNDP was a top down model where demand response assets and distributed energy resources were optimally dispatched by individual “transactive” nodes using two-way communications. Both both were generally more centralized paradigms.

The third transactive approach is a fully distributed edge control method that relies on pricing signals reflecting the prediction of future conditions creating a different price at many different scales.  Lower-level devices (or entire systems) respond to those pricing signals from higher levels. This method is currently being researched at Maine’s Brunswick Landing Microgrid Project (add link) for the Department of Energy.

While the first two transactive energy approaches have shown promise in that they have been able to balance energy demand, lowering peak demand and managing grid congestion they rely on large two-way communication networks that are particularly vulnerable to cyber assaults.

This cyber vulnerability should be a concern for the microgrid community because for a wide spread deployment of a system of microgrids this communication vulnerability is of particular concern to today’s infrastructure experts.

The edge-based system being researched at Brunswick Landing has pricing signals (potential of 10 or more different grid scales) are continuously re-calculated, only travel in a downward direction and are acted upon only by edge devices have promise, using the “power of complexity to lead to simplicity” Since the scope of influence of a single node is typically only one or two degrees of separation as described by Eric Berlow, this limits the computing power required to calculate the system state and provides for enhanced capabilities using advanced artificial intelligence techniques and limits security risks with limited communications routes. An effective transactive edge-based energy system can provide increased resilience, versatility, reliability and flexibility when used not only in microgrids but the greater electrical grid.

Kay Aikin is CEO of Introspective Systems, a complex systems architecture and engineering company in Portland Maine. Introspective Systems is the project lead at the Brunswick Landing Microgrid Project researching edge-based transactive energy networks.


  • 0

DOE Grid Architecture project

Tags :

New grid architecture promotes renewable energy

New grid architecture promotes renewable energy

Introspective Systems LLC, was awarded a $146,683 U.S. Department of Energy contract. The project running through March 13, 2017 will develop a new “future” grid architecture that puts intelligence on the edge of the grid.  The project is part of the DOE’s Grid Modernization Initiative.

Introspective Systems’ plan is based upon a fractal computer architecture xGraph developed by Introspective Systems.  xGraph distributes intelligence (analytics processing) to the edge of the computer network. It uses advanced theories in Complex Adaptive Systems (CAS) and Complexity theory. It also uses a unique concept utilizing a fractal structure.  A fractal is a natural phenomenon or a mathematical set that exhibits a repeating pattern that displays at every scale. Introspective Systems is using this concept and applying it to a computer architecture.

In the case of the electrical grid a single house would have a miniature electrical grid that would operate to save the homeowner electricity. Neighbors could then connect together to share infrastructure (solar panels, batteries etc.) within another small scale grid. Then neighborhoods group together pooling resources in the same way. This pattern would duplicate itself all the way up to the the entire nation. The algorithms running in each level of the electrical grid would be similar.

This would solve many problems in the current grid potentially making it more renewable, efficient, reliable and manageable while giving consumers choice. Most importantly the current grid is very vulnerable to terrorist cyber attack. This problem is being worked on by the Department of Energy, Department of Homeland Security as well as the Department of Defense. This fractal grid architecture approach could potentially solve these problems inherently. The structure of the grid would consist of fewer connections between layers. These fewer connections would make the electrical grid less vulnerable to being cyber-hacked.  If there was an attack fewer of these millions of smaller grids would be effected resulting in less damage.




  • 0
Systems in IoT World

Systems of Systems focused IoT Design

Tags :

As Internet of Things applications become more widespread software complexity with the system will grow exponentially. The IoT is not a single monolithic system but a system of systems. To cope, we must be able to create better architectures to manage these complex systems of systems.

Hardware has progressed tremendously in the last 40 years by encapsulation and Miniaturization. Numerous technologies have been encapsulated into single chips and miniaturized. This has sped time to market, processing speed and a host of benefits that have allowed Moore’s Law to be proven true. Software however has not scaled this way relying on monolithic architectures built around centralized databases that define how the pieces talk and work together. As systems architects we are designing IoT systems in much the same way as we design our applications. Some central brain with memory receives signals, makes decisions and sends signals to actuators for implementation.

The Internet scaled because each node (browser) provided processing and could be completely separated. A node operates independently and is separated from all other nodes. This is separation of concerns ideal in most good software design. This has been very successful for the Internet but it appears we are forgetting this lesson with Azure IoT and Samsung’s new Artik among others. When we design our Internet of things architecture we need realize the same separation of concerns but on a larger scale by decoupling our processes so everyone can be independent of each other. Centralized (ie: cloud data analytics) databases and architectures are a high friction architecture that only makes the solutions more complex. Security, communications and scaling being the biggest challenges for this centralized approach.

Nature doesn’t have this centralized “brain”. The swamp does not tell a cattail how to be a cattail, there is no “ecosystem” brain telling the cattail and swamp to communicate between themselves (in this case nutrients, water etc.) Each “thing” in the swamp is its own agent. But we are fundamentally designing the Internet of Things in an old paradigm where there is some central controller orchestrating the dance of the things.

We have to get to a systems thinking view of entire technical ecosystem. There are global goals but most of the thinking is done locally. Today in the environmental movement we hear the slogan “Think Globally act Locally” but this doesn’t say everything. If we literally applied this to the complex technological system world, we would build software architecture’s that have some kind of cloud controller. But what the environmental movement is really saying is to get back to natures’ principals. There is a global imperative, which, considers the entire architecture in its design and goals but the intelligence and actions are collaborative at the lowest level.

That doesn’t say that we only have local control and action. There are layers of control/action. So a group of cattails share a resource and create equilibrium between them. The frog uses the cattails roots as a place to hide its eggs and provides fertilizer to the cattails roots in exchange. And many groups of things (Cattails, frogs, fish etc) form the basis for the swamp and the swamp is one control/action network in a greater ecosystem of the watershed. This brings us to the concept of fractal layers. With fractal layers of control we can break larger systems up into systems of systems (SoS) and those systems into smaller systems. With those new SoS’s designs come possibilities for unique interactions and the optimal control of systems. One of the core principals in Systems of Systems science is how emergent behavior develops out of these interactions. This being a core benefit of AI systems.

On the 29th of April, Harvard Business Review posted an article “The Internet of Things needs Design, not just Technology” where they argue for the need of better product design in the Internet of Things. Producing value for the customer rather than just being a technology looking for a customer. Creating business value in data is driving most of the current solutions in the IoT space. What data can I, as a business, get from having an IoT device in a home? Not what value can I give to the consumer?

I believe the problem is even more fundamental than this business issue, in that we need to start with a fundamental design question. What architecture best serves the interests of the consumer? One that sends all information to the cloud or one that uses systems thinking to develop a more nature focused Systems of Systems that all levels of the ecosystem can benefit from.
